3.7V Rechargeable 25mah 80mah 200mah 1mm Thickness Small Curved Slim Mini Ultra Thin Lipo Polymery Battery

Products

LiFePO4 Energy Storage Battery

3.7V Rechargeable 25mah 80mah 200mah 1mm Thickness Small Curved Slim Mini Ultra Thin Lipo Polymery Battery

MOQ:	1000PCS
Price:	Negotiable
Standard Packaging:	Carton box
Delivery Period:	5-8 Work Days
Payment Method:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity:	10000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Certification

Model Number

014461

Capacity:

200mAh

Certifications:

Chemistry:

Lithium Polymer

Operating Temperature:

-20°C To 60°C

Type:

Rechargeable

Minimum Order Quantity:

1000PCS

Price:

Negotiable

Packaging Details:

Carton box

Delivery Time:

5-8 Work Days

Payment Terms:

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability:

10000pcs/day

Product Description

3.7V Rechargeable 25mah 80mah 200mah 1mm Thickness Small Curved Slim Mini Ultra Thin Lipo Polymery Battery

Battery Specification

1. Mechanical Characteristics
Cell	014461	PCM	No
NTC	No	Weight	appr. 4 g
Configuration	1S1P	Demension	14461mm(MAX)
2. Electrical Specification
Capacity	200mAh	Nominal Voltage	3.7V
Energy	0.74Wh	Internal Impedance	less than 300mΩ
Max. Charge Voltage	4.2V	Discharge Cut Off	2.75V
Max. Charge Current	200mAh	Max. Discharge Current	200mAh
Standard Charge Current	40mA	Standard Discharge Current	40mA
Charge Temp. Range	0℃ to 45℃	Discharge Temp. Range	-20℃ to 60℃
Storage Temp. Range	1 year at -20℃ to +30℃	Cycle life	100 cycles ≥92%
	3 months at -20℃ to +45℃		300 cycles ≥88%
	1 month at -20℃ to +60℃		500 cycles ≥80%
3. Cell protection
Overcharge Detection	-	Over discharge Detection	-
Overcurrent Detection	-	Short protection	-

For more information, welcome click "contact us" now!

① The ultra-thin lithium manganese battery with thickness range 0.3~1.5mm and length and

width of 8~80mm can be customized,rechargeable ultra thin lipo is availabe as well.

② We support the design of lithium battery products that meet your product requirements.

③ If you need to design the shape and casing of the product, we support a quick drawing

design to make the mold.

④ According to customer's request to custom processing!!!

Other Ultra thin lipo battery as below:

No	Model	capacity(mAh)	Voltage(V)	Thickness(mm)	Width(mm)	Length(mm)
1	AUK041850	12	3.7	0.47	18.5	50.5
2	AUK042126	8	3.7	0.50	21.8	26.1
3	AUK042255	20	3.7	0.47	22.5	55.5
4	AUK042323	8	3.7	0.47	0.5	23.5
5	AUK043030	15	3.7	0.47	30.5	30.5
6	AUK043228	15	3.7	0.47	32.5	28.5
7	AUK043251	25	3.7	0.47	32.5	51.5
8	AUK043526	12	3.7	0.47	35.0	26.5
9	AUK072247	30	3.7	0.70	22.8	47.8
10	AUK072836	30	3.7	0.70	28.0	36.0
11	AUK082025	14	3.7	0.80	20.5	25.5
12	AUK083960	100	3.7	1.00	39.5	60.5
13	AUK085045	100	3.7	0.80	50.0	45.5
14	AUK10180270	3,000	3.7	1.00	180.0	270.0
15	AUK20180270	6,000	3.7	1.80	180.0	270.0
16	AUK2029110	400	3.7	2.00	29.5	110.0

Company Information
